汽车音响~低音扬声器

性能与特点

Red aluminum basket with shinning painting

T-yoke and washer with electrophoresis black

High performance ferrite magnet

Pressed cone with black rubber surround

Heat-resistant EISv former and copper tinsel

技术参数

MODEL 13HP-15
Description 15"
Impedance 2+2 Ohm
Sensitivity 86dB
Freq Response 300hz-1200hz
Rms/Max Power 500W/1000W
Magnet Weight 312 oz
voice Coil Dia 3.5" EISv
TS Parameter bl 13.2
TS Parameter fo 32
TS Parameter vas 92
TS Parameter qts 0.725
Recommend vented box 120L
