汽车音响~低音扬声器

性能与特点

Red aluminum basket with shinning painting

T-yoke and washer with electrophoresis black

High performance ferrite magnet

Pressed cone with black rubber surround

Heat-resistant EISv former and copper tinsel

技术参数

MODEL 13HP-12
Description 12"
Impedance 2+2 Ohm
Sensitivity 85dB
Freq Response 200hz-1000hz
Rms/Max Power 400W/800W
Magnet Weight 242 oz
voice Coil Dia 2.5" EISv
TS Parameter bl 11.84
TS Parameter fo 30
TS Parameter vas 86
TS Parameter qts 0.694
Recommend vented box 60L
