Black steel basket with matt painting
T-yoke and washer with black painting
High performance ferrite magnet
PP cone with rubber surround
Heat-resistant KSv former and copper tinsel
| MODEL | 13CC-502 |
| Description | 5.25" Coaxial |
| Impedance | 4 Ohm |
| Sensitivity | 87dB |
| Freq Response | 100hz-20Khz |
| Rms/Max Power | 35W/70W |
| Magnet Weight | 6.3 oz |
| voice Coil Dia | 0.75" KSv |
| System | 2 Way |
| Tweeter | 1" Mylar |
| Crossover | 6dB/oct |
| Mounting depth | 50mm |
