Black steel basket with matt painting
T-yoke and washer with black painting
High performance ferrite magnet
PP cone with rubber surround
Heat-resistant KSv former and copper tinsel
| MODEL | 13CC-573 |
| Description | 5x7" Coaxial |
| Impedance | 4 Ohm |
| Sensitivity | 87dB |
| Freq Response | 65hz-20Khz |
| Rms/Max Power | 40W/80W |
| Magnet Weight | 9.8 oz |
| voice Coil Dia | 1" KSv |
| System | 3 Way |
| Tweeter | 1" Mylar |
| Crossover | 6dB/oct |
| Mounting depth | 62mm |
