Black steel basket with shinning painting
Electric white zinc T-yoke and washer
High performance ferrite magnet
PP cone with black rubber surround
Heat-resistant KSv former and copper tinsel
| MODEL | 13CB-682 |
| Description | 6x8" Coaxial |
| Impedance | 4 Ohm |
| Sensitivity | 87dB |
| Freq Response | 60hz-20Khz |
| Rms/Max Power | 40W/80W |
| Magnet Weight | 8.5 oz |
| voice Coil Dia | 1″KSV |
| System | 2 Way |
| Tweeter | 1" Mylar |
| Crossover | 6dB/oct |
| Mounting depth | 66mm |
