汽车音响~同轴与套件扬声器

性能与特点

Black steel basket with shinning painting

Electric white zinc T-yoke and washer

High performance ferrite magnet

PP cone with black rubber surround

Heat-resistant KSv former and copper tinsel

技术参数

MODEL 13CB-402
Description 4" Coaxial
Impedance 4 Ohm
Sensitivity 85dB
Freq Response 95hz-20Khz
Rms/Max Power 35W/70W
Magnet Weight 8.5 oz
voice Coil Dia 1″KSV
System 2 Way
Tweeter 1" Mylar
Crossover 6dB/oct
Mounting depth 50mm
