| MODEL | 12CD-104 | |
| DESCRIPTION | 10" Subwoofer | |
| IMPEDANCE | Dual 4 OHM | |
| SENSITIVITY(1W/1m ） | 85dB | |
| FREQ RESPONSE | 29HZ-500HZ | |
| Rate/Max Power | 300W/600W | |
| MAGNET WEIGHT | 40 Oz | |
| VOICE COIL DIA. | 2" KSV | |
| TS Parameter | Fo | 28 |
| Vas | 29.2 | |
| Qts | 0.43 | |
| RECOMMEND VENTED BOX | Box volume | 35L |
| Fb | 37Hz | |
| Inverter Tube | Ф78 × 254mm | |
| RECOMMEND SEALED BOX | NA | |
